Hitachi EX, LX & ZAXIS ZX Excavator Parts Catalog PDF Manual Collection
This comprehensive Hitachi Parts Catalog PDF Collection provides detailed illustrated parts information for a wide range of Hitachi EX Series excavators, LX Series wheel loaders and ZAXIS / ZX Series excavators. The collection contains multiple individual PDF parts catalogs covering different models, series and machine configurations.
This collection is a valuable technical resource for heavy-equipment technicians, mechanics, workshop personnel, fleet owners, parts departments and Hitachi equipment owners who need accurate reference information for identifying replacement parts and machine components.
Include Models
EX Series: EX60, EX60-2, EX60-5/EX80-5, EX100-2, EX100WD, EX120, EX120-2, EX120-5/EX130-5, EX160WD, EX200, EX200-2, EX200-5/EX210-5, EX220, EX220-2, EX220-5/EX230-5, EX270-5/EX280-5, EX300, EX300-2, EX300-5/EX370-5, EX400 and EX400-5/EX450-5.
LX Series: LX110-7, LX130-7, LX150-2, LX160-7 and LX190-7/LX230-7.
ZAXIS / ZX Series: ZX25, ZX110, ZX160, ZX180, ZX200/ZX210/ZX240, ZX230/ZX240/ZX250, ZX270/ZX280, ZX330/ZX350/ZX370, ZX450/ZX460/ZX480, ZX450-3/ZX470-3/ZX500-3/ZX520-3, and ZX600/ZX650
Manual Specifications
| Manufacturer | Hitachi |
|---|---|
| Series | EX, LX & ZAXIS / ZX Series |
| Equipment Type | Excavators & Wheel Loaders |
| Manual Type | Parts Catalog / Parts Manual Collection |
| Models Covered | Multiple Hitachi EX, LX and ZAXIS / ZX models |
| Format | Multiple PDF Manuals |
| Language | English |
| Download Size | 1.4 GB |
| Document Type | Digital Parts Catalog Collection |
| Compatibility | Windows, macOS, Linux, Android & iOS |
| Delivery | Instant Digital Download |
What’s Included
- Multiple Hitachi OEM-style parts catalog PDF manuals
- Hitachi EX Series excavator parts catalogs
- Hitachi LX Series wheel loader parts catalogs
- Hitachi ZAXIS / ZX Series excavator parts catalogs
- Illustrated parts diagrams and component breakdowns
- Part identification and reference information
- Coverage for multiple machine generations and variants
- Digital PDF collection for convenient workshop reference
Systems and Components Covered
- Engine-related components and mounting parts
- Hydraulic system components
- Main pumps, valves and hydraulic lines
- Upperstructure and revolving frame components
- Boom, arm and bucket components
- Travel devices and undercarriage components
- Swing system components
- Cab, operator station and body components
- Electrical components and related parts
- Fuel and cooling system components
- Chassis and structural components
- Fasteners, fittings and associated hardware
